| General: | |
| Model No | MW-1854DPF/WDPF |
| H.S. Code | 8543709990 |
| Warrant | Standard 1 year |
| Basic Features: | |
| Remote control | Full functions IR remote control |
| Timer | Set time power on/off at specific time, self-working. |
| Playback | Auto start and playback, loop when power on |
| Multi-language | English, Spanish, Franch, Italian, German..etc |
| Speakers | Build-in stereo 2*2W speakers |
| Playing mode | Slideshow, slideshow+music(BGM mode), video |
| Image display mode | Slideshow, preview, rotation |
| Setting | Brightness, contrast ratio, color adjustable, calender, clock, alarm clock |
| Backlit | LED backlit, energy-efficient and more life time. |
| Contents update | Easily update media files from USB key to internal memory or SD memory card. |
| Certification | CE /FCC/ROHS |
| Panel: | |
| Panel Size | 18.5inch LCD |
| Max Resolution | 1366*768 |
| Aspect Ratio | 16:9 |
| Viewing Angle | 80/80/80/80 |
| Contrast Ratio | 800:1 |
| Brightness | 350nits |
| Response Time | 8 ms |
| Lamp Type | WLED |
| Power Input | 110-240v |
| DC Output | 12V, 2A |
| Physical Characteristics: | |
| Product Weight | 2.32KGS |
| Outlook Dimensions | 461.3*281.7*12MM |
| Display Area | 408.7*229.1MM |
| Color | Black, white or optional |
| Housing Material | Plastic |
| Installation | Desktop, wall-mounting, shelf mounting |
| Extendable Options: | |
| Motion sensor | For auto power ON/OFF or sound/mute or play/stop |
| Battery powered | External battery pack. |
| IPS Panel | High quality colorful display, high view angle L/R/U/D 80/80/80/80 |
| Gravity Sensor | Auto rotation picture when vertical display or horizontal display |
| Internal Memory | Auto copy new contents to internal memory from USB key. |
| Camera | 500MP |
| Touch screen | Capacitive(PCAP)touch |
| High brightness | 350nits up to 1000nits |
| External buttons | Support max 6 external buttons with custom functions, like power ON/OFF, play corresponding video,pause/play, mute/sound, last/next |
| Logo printing | Silk screen printing or laser printing |
| Start image logo | Setting your company logo as the start image/video |
| Front glass cover | Front tempered glass to protect the screen from water or bump |
| Metal Housing | Open frame type or wall mount type |
| Accessories: | |
| Power Adaptor, Bracket, Remote Control, Use Manual | |
| Packing Details: | |
Carton size | 610*440*410MM |
| Unit/Carton | 5PCS |
| G.W./Carton | 20KGS |
1. Solution: A64/RK3288/RK3566//RK3568
2. Android OS 6.0/7.1/8.1/11.0
3. RAM 1GB/2GB/4GB(DDR)
4. Flash 8GB/16GB/32GB
5. WiFi 802.11b/g/n
6. Mobile network 3G/4G , GPS are optional
7. Contents Management Software(CMS) optional
8. I/O interface: 3*USB, 1*SD card slot, 1*RJ45 port,
HDMI output *1（optional）
Plug And Play Advertising Display
1. Auto playback and loop 1080P video/picture/music
2. Play from SD card reader/USB ports/internal memory
3. Auto update contents from USB key to internal memory
4. Set time power ON/OF at specific time
5. Support rolling caption in different color and effect
6. Support portrait/landscape display
7. HDMI input for contents from other sources
8. I/O interface: 1*USB,1*SD card slot,HDMI input *1
